Nidec/Emerson Condenser Fan Motor 1/5 HP 1075 RPM 2

The Nidec/Emerson 2246 is a 1/5 horsepower, 1075 RPM condenser fan motor for outdoor fan applications in air conditioning and refrigeration condensing units.

One fifth horsepower sits between the more common one-sixth and one-quarter sizes and is specified where the fan load falls between them. It is worth matching rather than rounding to a neighbouring size: fitting a smaller motor leaves it running above its rating, while fitting a larger one is generally harmless electrically but may not fit the mounting or may alter the fan's operating point if the blade is changed with it.

The compact frame dimensions of this motor suit equipment where cabinet space above the coil is limited, which is common in refrigeration condensing units and in slimline outdoor sections.

Bearing type is worth confirming when selecting a replacement. Sleeve bearings are quieter and less expensive; ball bearings tolerate higher loads, higher temperatures, and shaft-up or horizontal mounting better. The original motor's bearing type reflects the application's demands.

The motor requires a permanently connected run capacitor of the specified value.

Confirm horsepower, RPM, voltage, rotation, frame diameter, shaft diameter and length, and mounting arrangement before ordering.

Brand

Nidec/Emerson

SKU

2246

Category

Condenser Fan Motors

Weight

10 lbs

Dimensions

7.61" x 5.00" x 5.59"

Price

$162.00

Availability

In stock

Rating

0 / 5.0
