ECCO B-Vent Pipe 506INC 5 To 6 Double Wall Increaser

The ECCO 210558 is a double wall Type B vent increaser transitioning from 5 inch to 6 inch diameter.

Transitions at these sizes almost always relate to common venting. Where two gas appliances share a vent, typically a furnace and a water heater, the common vent must be sized for the combined input, and that frequently calls for a larger diameter than either connector. The increaser is fitted at the point where the connectors join the common vent and the run continues upward at the larger size.

Common vent sizing is governed by dedicated tables in the fuel gas code that account for the input of each appliance, the height of the common vent, the rise of each connector, and the lateral lengths involved. It is not a matter of adding diameters or applying a rule of thumb.

A frequently encountered situation is the orphaned water heater: a furnace is replaced with a high efficiency condensing model that vents separately in PVC, and the water heater is left alone on a common vent sized for both appliances. The vent is now grossly oversized for the remaining load, the flue gases cool and condense, and the liner corrodes. That scenario requires the vent to be resized or relined, not simply reconnected.

Applications include residential and light commercial gas furnace, boiler, and water heater venting.

Brand

ECCO

SKU

210558

Category

B-Vent Pipe & Fittings

Weight

0.95 lbs

Dimensions

6.00" x 6.50" x 6.50"

Price

$50.00

Availability

In stock (3 available)

Rating

0 / 5.0
