DiversiTech Conduit 3/4" 100 750-34100

The DiversiTech 750-34100 is 3/4 inch flexible conduit in a 100 foot length, supplied for protecting and routing conductors in mechanical and equipment installations.

The 3/4 inch trade size accommodates larger conductors and higher conductor counts than 1/2 inch conduit, suiting equipment with substantial minimum circuit ampacity, three phase connections, and runs carrying multiple circuits. Adequate conduit size is not optional; conduit fill limits exist because crowded raceways make conductors difficult to pull without insulation damage and impair heat dissipation, which reduces allowable ampacity.

Flexible conduit is the standard raceway for final equipment connections in HVAC work. It absorbs the vibration produced by compressors and fans, routes around obstructions without the fitting count that rigid conduit would require, and permits limited equipment movement during service access.

Bulk conduit rather than a prefabricated whip allows exact length setting, which is useful where equipment placement varies between installations or where standard whip lengths would leave excessive slack or fall short of the disconnect.

Applications include condensing unit and packaged equipment connections, air handler and blower wiring, mechanical room raceway routing, refrigeration equipment installation, and general commercial and industrial work.

Observe code requirements for support spacing, maximum distance to boxes and terminations, and minimum bend radius. Determine whether the conduit type and installation permit it to serve as an equipment grounding conductor; where it does not, pull a separate grounding conductor. Confirm the conduit type is rated for the installation environment, particularly in wet, outdoor, or corrosive locations.

Brand

DiversiTech

SKU

750-34100

Category

Conduit & Fittings

Weight

22 lbs

Dimensions

22.00" x 22.00" x 6.50"

Price

$164.00

Availability

In stock (4 available)

Rating

0 / 5.0
