DiversiTech Run Capacitor 440V 50MFD PRCF50A

The DiversiTech PRCF50A is a 50 microfarad, 440 volt round run capacitor for single-phase compressor and motor applications in HVAC and refrigeration equipment.

Run capacitors retain a stored charge after power is removed, and that charge is capable of delivering a painful and potentially dangerous shock. Before handling any capacitor, isolate the equipment, verify the absence of supply voltage, and discharge the capacitor deliberately.

The correct method is to discharge through a resistance, using a resistor of a few thousand ohms with an adequate wattage rating connected across the terminals for several seconds. Shorting the terminals with a screwdriver blade, still a widespread practice, produces a high current arc that pits the terminals, damages the tool, and can spatter molten metal. On a dual capacitor, each section must be discharged separately, and each should be discharged to the common terminal.

After discharging, confirm with a meter that no voltage remains before touching the terminals.

Fifty microfarad is a compressor run value used on larger residential and light commercial condensing units.

Confirm capacitance, voltage rating, case diameter and height, and terminal configuration before ordering.

Brand

DiversiTech

SKU

PRCF50A

Category

Capacitors

Weight

0.82 lbs

Dimensions

4.75" x 2.50" x 2.50"

Price

$23.00

Availability

In stock (1 available)

Rating

0 / 5.0
