Sitex MDA-5H Class B AIS No Wifi

Sitex MDA-5H Class B AIS No Wifi

Si-tex SKU: TCW-99392 (0)
$1,049.99 /each
In Stock — get it by Fri, Aug 7
  • Shipping charges may apply
  • Usually ships within 3 days
  • Restocking fees may apply

Can't find the exact part? Request it and we'll source it for you.

Request Part
Product Highlights
Warranty Manufacturer backed
0 / 5 0 reviews
In Stock Ships fast
Si-tex Authentic part
Description

Sitex MDA-5 Class B+ SOTDMA AIS Transceiver NO Wifi

Model: MDA-5H
  • The MDA-5 is the world's most sophisticated fully certified 5-Watt SOTDMA Class B AIS Module on the market
  • 5-Watt transmitter power, Higher Output power means your vessel will be seen at longer ranges by other vessels and via AIS websites
  • SOTDMA Class A Priorities means that your vessel will always transmit and be seen in very congested Commercial Harbors and Ports where traditional Class B units don't have network priority.
  • Integrated zero loss VHF antenna splitter - no second antenna needed
  • Water Proof certified to IPX7
  • NMEA-0183 data port, NMEA-2000 & USB intelligent connectivity to all bridge systems
  • Built-In GPS & GLONASS satellite navigation receiver
  • 2 Year Warranty
  • Dual Receivers decodes all DSC & AIS messages, including MOB & SART
  • Ultra-power efficient
  • IEC-62287-2, FCC and USCG certified
Specifications
Transmitter Output Power
5 Watts
VHF Antenna ConnectorSO-239 UHF
GPS Antenna ConnectorTNC
Frequency Range156.025 - 162.025 Mhz
Input Voltage9.6-31.2 Vdc
Current Draw220mA Average Power Consumption
Operating Temperature Range-25 degC - +55 degC
Ingress ProtectionIP67
Dimensions - Transceiver6.8 W x 5.0 in H x 2.0 in D

What's in the Box:
  • MDA-5H Transceiver
  • Commercial Grade External GPS Antenna with Coax Cable
  • Mounting hardware
  • Power & Data Interface cable
  • VHF Radio Connection cable
  • Product information DVD
Specs
Brand
Si-tex
SKU
TCW-99392
Category
AIS Transceivers & Receivers
Weight
1.69 lbs
Dimensions
10.0 x 8.0 x 4.0
Price
$1,049.99
Availability
In stock
Rating
0 / 5.0
