Newmar 460-2470-0 12-24-7 Step Up DC-DC Converter 7AMP Conitnuos
- Shipping charges may apply
- Usually ships within 3 days
- Restocking fees may apply
Can't find the exact part? Request it and we'll source it for you.
Product Highlights
Description
These "UP" converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on marine vessels without having to install a 24 volt battery and dedicated charging system. Choose from two types depending on your application:
In the Standard, Non-Isolated Series the 12V input and 24V output share a common negative ground and are ideal when installing certain electronics that operate better on 24 volts when a robust 12 volt system exists. Models available in outputs of 7, 16 and 25 amps.
Standard, Non-Isolated Series- Intended for use on negative ground systems
- 10 -15 VDC input range
- Available in 7, 16 and 25 amp outputs
- Current limited, voltage spike suppression, automatic thermal shutdown and recovery
| Lbs | Kg | ||||||
| 12-24-7 | 10-15 | 27.2 | 7 | 7 | C-1 | 1.4 | .64 |
| 12-24-16 | 10-15 | 27.2 | 16 | 16 | C-2 | 3.55 | 1.61 |
| 12-24-25 | 10-15 | 27.2 | 25 | 25 | C-3 | 4.1 | 1.86 |
| H | W | D | H | W | D | ||
| C-1 | 3.5 | 3.5 | 1.75 | 8.9 | 8.9 | 4.5 | |
| C-2 | 4.25 | 5.9 | 14.0 | 10.8 | 15.0 | 35.6 | |
| C-3 | 6.0 | 6.8 | 16.5 | 15.2 | 17.3 | 41.9 |
Input: 10 - 15V DC
Output: 27.2 VDC +/-5% at extreme temperature load, input, tolerance, etc.
Ripple: <100mV P-P
Regulation: +/- 5% Line/Load
Duty Cycle:
Intermittent: 2 minutes, 20% duty
Continuous: 24 hours, 100% duty
Operating Temp: -25 ̊ - 30 ̊ C, derate linearly from 30 to 0% @ 80 ̊ C
Mechanical- Efficiency: 93% - Typical.
- Anodized aluminum, glass filled polycarbonate, dust water and impact resistance to IP533
- Front panel terminal block
- Output indicator: Green LED
Specs
- Brand
- Newmar
- SKU
- I1O-71777
- Category
- Solar & DC-DC Converters
- Weight
- 3 lbs
- Dimensions
- 10.0 x 8.0 x 4.0
- Price
- $445.00
- Availability
- In stock
- Rating
- 0 / 5.0
