Mars Fuse Cartridge 40A 600V 82140

The Mars 82140 is a 40 amp, 600 volt cartridge fuse used for branch circuit and feeder protection in commercial and industrial electrical systems.

The 600 volt rating extends application well beyond residential work, covering 480 volt three phase distribution common in commercial buildings, industrial plants, and larger rooftop mechanical equipment. Fuse voltage rating must equal or exceed the circuit voltage; applying a lower-rated fuse is unsafe because it may not reliably interrupt an arc at higher system voltage.

At 40 amps, this fuse commonly serves motor branch circuits, condensing unit feeds, packaged rooftop equipment, and distribution subfeeds in light commercial installations.

Applications include fused safety switches and disconnects at mechanical equipment, motor control centres, panelboard and switchboard protection, three phase compressor circuits, and general industrial distribution.

When replacing a cartridge fuse, matching amperage alone is insufficient. The class designation governs both interrupting rating and time-current response, and the equipment in which the fuse is installed carries a listing tied to specific fuse classes. Substituting a fast-acting fuse into a motor circuit designed for time delay will cause repeated opening on startup, while a fuse with inadequate interrupting rating may fail destructively rather than clearing a fault.

Verify the class, voltage rating, amperage, dimensions, and delay characteristic against the original. Before servicing, de-energize and lock out the circuit and confirm absence of voltage with a meter. Inspect the fuse clips for discoloration, pitting, or weak spring tension, as poor clip contact generates heat and causes premature fuse failure.

Brand

Mars

SKU

82140

Category

Fuses

Weight

0.33 lbs

Dimensions

5.50" x 1.06" x 1.06"

Price

$34.00

Availability

In stock

Rating

5 / 5.0
