Mars Fuse Cartridge 15A 600V 2" M82134

The Mars M82134 is a 15 amp, 600 volt cartridge fuse in a 2 inch body, used for control circuit and small load protection in commercial and industrial equipment.

The 600 volt rating allows this fuse to be applied across the full range of standard industrial system voltages, including 480 volt three phase distribution, while the compact 2 inch body suits the fuse blocks and holders used inside control panels where space is constrained. Body dimensions must match the holder; cartridge fuses of identical amperage are made in multiple lengths and diameters, and an undersized fuse will make poor or no contact.

At 15 amps, typical applications are control transformer primary protection, control circuit branches, small motor circuits, instrumentation and electronic control power, solenoid and valve circuits, and accessory loads within equipment panels.

Control circuit protection has a diagnostic value beyond equipment protection. When a fuse opens, it confirms a fault exists downstream and directs troubleshooting toward the control wiring and components rather than the transformer. Without protection, the same fault destroys the transformer and turns a simple repair into a parts-and-return-visit job.

Verify the class designation, voltage rating, amperage, body dimensions, and whether the original was fast-acting or time delay. Control transformers and solenoid circuits usually require time delay to survive energization inrush, while purely resistive and electronic loads may specify fast-acting for tighter protection.

De-energize and lock out the panel and confirm absence of voltage before replacing any fuse or working in the control compartment.

Brand

Mars

SKU

M82134

Category

Fuses

Weight

0.17 lbs

Dimensions

5.00" x 0.81" x 0.81"

Price

$22.00

Availability

In stock

Rating

4.9 / 5.0
