Lumishore 010-04448-00 LUX Speaker Light Driver

Name: Lumishore 010-04448-00 LUX Speaker Light Driver
Brand: Lumishore
SKU: FVW-78656
Price: 225.00 USD
Availability: InStock

Lumishore SKU: FVW-78656 (0)

$225.00 /each

In Stock — get it by Fri, Aug 7

Shipping charges may apply
Usually ships within 3 days
Restocking fees may apply

Can't find the exact part? Request it and we'll source it for you.

Request Part

Product Highlights

Warranty Manufacturer backed

0 / 5 0 reviews

In Stock Ships fast

Lumishore Authentic part

Description

Lumishore LUX Speaker Light Driver

Model: 010-04448-00

Plug in your audio system via the EOS-LUX Command Center's mini jack and enjoy Lumishore's unique sound-to-light experience.

By analyzing music signals and splitting them into 3 frequency bands, the Speaker Light Driver allows you to select colors for each frequency - a dynamic lighting experience, from one song to the next! Pulse your Lumishore lights to the frequency of the music, in any color, cycle, or oscillating pattern.

For use with CRGBW (cold white, red, green, blue, warm white) and RGB (red, green, blue) LED Marine Speakers.

Easily controllable by a momentary switch, with the option to upgrade to full integration with your compatible MFD and/or Lumishore Display.

Controls up to 16 speakers and is finished with powder coated marine grade aluminium.

Specifications
For Use

With CRGBW (Cold white, Red, Green, Blue, Warm white) and RGB (Red, Green, Blue) LED Marine Speakers
Ingress Protection	IP68
Supply Voltage Range	10.5 - 31 V DC
Max Current Draw	5.6A / 2.8A
Surge Protection	Yes
ATRB (Automatic Thermal Roll Back)	Yes
Low Voltage Protection	Yes
Reverse Polarity Protection	Yes
In Rush Current Protection	Yes
Max Cable Length to First Speaker	5m (16.8 feet)
Number of Speakers per Driver	16
Size	Not Including Cable Glands or cables (LxWxH) - 113mm x 79mm x 27mm
Case Construction	Powder Coated Marine Grade Aluminium
Control options	Momentary switch or upgrade to full MFD and optional Display
