Furuno DT-800MSF Bronze TH NMEA2000 Depth and Temp
Brand:
Furuno
SKU: FURDT800MSF
Availability:
In Stock
1 available
Ships fast from our US warehouses
$400.00
/each
Secure Checkout
100% Genuine Parts
Manufacturer Warranty
Ships from USA
Secure Payments
30DAY
Easy Returns
Fast Shipping
Product Highlights
Warranty
Manufacturer backed
0 / 5
0 reviews
In Stock
Ships fast
Furuno
Authentic part
Description
Furuno DT-800MSF Depth and temperature in one compact bronze housing
Model: DT-800MSF- Depth and temperature in one compact bronze housing
- Fast-response temperature sensor provides ±0.2 degC (±0.1 degF) accuracy
- Acoustic Window: Urethane
Designed with Airmar's exclusive Broadband Ceramic Technology, the DT-800MSF's 235 kHz element improves resolution without sacrificing sensitivity. The higher power rating 100 W RMS provides spot-on depth readings in as little as 0.45 m (1.4 feet) of water and can reach depths up to 180 m (600 feet).
Specifications| 1.5 kg (3.4 lb) | |
| Data Update Rate | 1 per second |
| Minimum Sounding Depth | 0.5 m (1.6 feet) |
| Maximum Sounding Depth | 180 m (590 feet) |
| Pressure Rating | 3 m (10 feet) |
| Pulse Rate | 20,000 p/nm* (5.6 Hz per knot)-*p/nm = pulses per nautical mile |
| Smart Sensor Supply Voltage at 100% Sound Power Output | 10 VDC to 25 VDC |
| Supply Current | 40 mA S |
| tandard Cable Length | 6m |
| NMEA 2000(R) Load Equivalency Number (LEN) | 4 |
Specs
- Brand
- Furuno
- SKU
- FURDT800MSF
- Category
- NMEA 2000 Cables & Connectors
- Weight
- 5 lbs
- Dimensions
- 6.0 x 4.0 x 2.0
- Price
- $400.00
- Availability
- In stock (1 available)
- Rating
- 0 / 5.0
