EGIS 3221-10 A Series Red Toggle Panel Mount Circuit Breaker Single Pole AC/DC 10 Amp Retail Pack
$34.99
/each
In Stock
— get it by Fri, Aug 7
- Shipping charges may apply
- Usually ships within 3 days
- Restocking fees may apply
Can't find the exact part? Request it and we'll source it for you.
Product Highlights
Warranty
Manufacturer backed
0 / 5
0 reviews
In Stock
Ships fast
Egis Mobile Electronics
Authentic part
Description
EGIS A Series Red Toggle Panel Mount Circuit Breaker Single Pole AC/DC 10 Amp Retail Pack
Model: 3221-10- AC & DC Rated to cover a wide range of system application needs.
- Stainless Steel Self Locking Hardware ensures robust connections & long term connection reliability.
- Easily Mounts In Standard Panels accepting A-Series and C-Series magnetic-hydraulic circuit breakers. Includes mounting screws .
- 4 Year Warranty: We stand behind our product's ability to meet your needs.
Protects Electrical Circuits allows from short circuit events and over-current loads, preventing wire insulation overheating and subsequent destruction..
High Interrupt Current to safely protects circuits connected to large paralleled battery banks with significant available power.
Specifications| CONTINUOUS CURRENT (AMPS) | 10 |
| MAX VOLTAGE | 277 Vac / 80 Vdc |
| Regulatory Compliance | UL 1077 |
| Electrical Endurance @ Rated current | 6,000 Cycles |
| Interrupt Capacity | 5kA / 277Vac, 1.5kA / 80 Vdc |
Specs
- Brand
- Egis Mobile Electronics
- SKU
- BYB-85987
- Category
- Circuit Breakers
- Weight
- 0.15 lbs
- Dimensions
- 5.0 x 4.0 x 2.0
- Price
- $34.99
- Availability
- In stock
- Rating
- 0 / 5.0
