Blue Sea 7040-BSS 187-Series 60 Amp Circuit Breaker Panel Mount
Brand:
Blue Sea Systems
SKU: VYW-89450
Availability:
In Stock
Ships same day if ordered by 12 pm
3.8
(18 reviews)
$94.99
/each
Secure Checkout
100% Genuine Parts
Manufacturer Warranty
Ships from USA
Secure Payments
30DAY
Easy Returns
Fast Shipping
Can't find the exact part? Request it and we'll source it for you.
Product Highlights
Warranty
Manufacturer backed
3.8 / 5
0 reviews
In Stock
Ships fast
Blue Sea Systems
Authentic part
Description
Blue Sea Systems 187-Series Circuit Breaker - Panel Mount 60A
Model: 7040-BSS- Combines switching and circuit protection into a single device*
- Clear, single lever operation
- Trip Free" design cannot be held "ON" during fault current condition
- Waterproof
- Recessed mounting holes for clean appearance
- Large Clearance around terminal studs accept heavy gauge wire lugs
- Robust 5/16 M8 terminals provide high torque connections
- Large lever with vertical/horizontal orientation provides indication of trip status
- Ignition protected - Safe for installation aboard gasoline powered boats
* Do not use as a switch where high inrush currents are expected.
Specifications| 60A | |
| Maximum Voltage | 48vDC |
| Mounting | Panel Mount |
| Circuit Breaker Type | Thermally responsive Bi-metal blade |
| Terminal Stud Torque | 75 in-lb (8.47 Nm) |
| Interrupt Capacity | 5000A @ 12V |
Specs
- Brand
- Blue Sea Systems
- SKU
- VYW-89450
- Category
- Circuit Breakers
- Weight
- 0.5 lbs
- Dimensions
- 5.0 x 4.0 x 2.0
- Price
- $94.99
- Availability
- In stock
- Rating
- 3.8 / 5.0
